Aluminum Trailers

Aluminum ATV Tube Top

Loading and unloading multiple ATV’s or other equipment is a breeze with the Sure-Trac Aluminum ATV Utility Trailer.  The aluminum frame provides a lighter trailer for towing and a finish that is nearly maintenance free while providing years of dependability.  The heavy duty bi-fold gate allows for easy rear loading and the side-storing aluminum ramps are easy to handle for side loading additional equipment.  Aluminum wheels, LED Lighting, and enclosed wiring are just a few details to prolong the life of your investment.

Features

  • 3" x 2" x 3/16" Aluminum Angle Frame
  • 4" x 2" Aluminum Tube Tongue
  • 2" x 2" Tube Top Rail
  • Tube Uprights
  • 2" A-Frame Coupler (Single Axle)
  • 2-5/16" A-Frame Coupler (Tandem Axle)
  • Safety Chains
  • 4-Way Molded Plug (Single Axle)
  • 7-Way RV-Style Molded Plug (Tandem Axle)
  • Enclosed Wiring
  • Swivel Jack with Caster Wheel (Single Axle)
  • 2K Setback Jack (Tandem Axle)
  • 54" Bi-Fold Aluminum Ramp Gate
  • 5' Aluminum Ramps (Side Storing)
  • Aluminum Fenders
  • Easy Lube Hubs
  • Brakes on Both Axles (Tandem Axle)
  • 15" Radial Tires
  • Aluminum Wheels
  • Wheel Assembly, 205 75R15 LRC
  • Extruded Aluminum Flooring
  • Stake Pockets
  • Spare Tire Carrier
  • All LED Lights

Specifications

  • 7' x 12' 3K
  • 7' x 14' 3K (SA)
  • 7' x 14' 7K (TA)
  • 7' x 16' 7K
  • GVWR (lbs)
  • 7' x 12' 3K 2990
  • 7' x 14' 3K (SA) 2990
  • 7' x 14' 7K (TA) 2990
  • 7' x 16' 7K 2990
  • GAWR (lbs/axle)
  • 7' x 12' 3K 3500
  • 7' x 14' 3K (SA) 3500
  • 7' x 14' 7K (TA) 3500
  • 7' x 16' 7K 3500
  • Curb Weight
  • 7' x 12' 3K 695
  • 7' x 14' 3K (SA) 735
  • 7' x 14' 7K (TA) 1230
  • 7' x 16' 7K 1240
  • Payload
  • 7' x 12' 3K 2805
  • 7' x 14' 3K (SA) 2255
  • 7' x 14' 7K (TA) 5770
  • 7' x 16' 7K 5760
