Pro Series Full-Width Equipment Trailer
Bed Width:
8.5'
Bed Length:
18' - 22'
GVWR:
15,400 - 22,000 lbs
Load Capacity:
10,950 - 17,583 lbs
Key Benefits
Extended (72″) Tongue
Provides exceptional structural integrity and stability and the extra length makes it easier to maneuver the trailer in tight spaces.
HD Bulkhead with Tie-Down
Adds additional rigidity to the front end of the trailer and provides versatility with additional option for securing your cargo.
HD 2-Speed 12k Drop Leg Jack
Speeds up the retraction of the jacks saving you time and energy.
HD 4″ Channel Mesh Covered Stand-Up Ramps
Extra wide ramps provide extra space for safe loading and the mesh provides a smoother surface to accommodate a variety.
Heavy Duty Tread Plate Outriggers and HD Reinforced Drive-Over Fenders
Provides a full-width deck to accommodate vehicles with a wider wheel base or large tires.
Extra Large Stake Pockets
Additional tie-down points that accommodate larger commercial straps for properly securing your equipment.
Why Choose a Sure-Trac Pro Series Full-Width Equipment Trailer?
Constructed with durable I-beam, this trailer is available in GVWR options of 15.4K, 17.6K, and 22K. The 22K model features single wheel 10K axles, providing the strength needed to handle even the heaviest loads without the bulkiness of dual wheels or tri-axle setup. Whether you’re transporting side-by-sides, an off-road jeep, or larger machinery, this trailer is designed to meet the demands of any job.
For added convenience, the Pro Series trailer features a 3-foot cleated beavertail that enhances loading and unloading capabilities. Coupled with heavy-duty 4-inch ramps that are 24 inches wide and covered in mesh, this setup ensures an ultimate loading experience, making it easy to roll vehicles onto the trailer safely and securely.
The design also includes an oversized toolbox with an integrated LED light for easy access to tools and supplies, even in low-light conditions. Oversized stake pockets add flexibility for securing a variety of loads, ensuring your equipment is transported safely.
This trailer excels in both functionality and ease of use, making it a reliable option for recreational and commercial applications alike. Whether you’re gearing up for a weekend adventure or transporting essential equipment for work, the Pro Series Full-Width Equipment trailer is your dependable partner, designed to handle a wide range of vehicles and equipment with confidence and ease.
Red
Orange
Yellow
Green
Blue
Gray
Models & Sizes
8.5 x 18
(15+3) Pro Series Full Width Equipment 15.4K
15,400 lbs
Model #:
CBIT10218-BP-154
GVWR:
15,400 lbs
GAWR:
7,000 lbs/axle
Curb Weight:
3,775 lbs
8.5 x 18
(15+3) Pro Series Full Width Equipment 17.6K
17,600 lbs
Model #:
CBIT10218-BP-176
GVWR:
17,600 lbs
GAWR:
8,000 lbs/axle
Curb Weight:
4,125 lbs
8.5 x 18
(15+3) Pro Series Full Width Equipment 22K
22,000 lbs
Model #:
CBIT10218-BP-220
GVWR:
22,000 lbs
GAWR:
10,000 lbs/axle
Curb Weight:
4,417 lbs
8.5 x 20
(17+3) Pro Series Full Width Equipment 15.4K
15,400 lbs
Model #:
CBIT10220-BP-154
GVWR:
15,400 lbs
GAWR:
7,000 lbs/axle
Curb Weight:
4,110 lbs
8.5 x 20
(17+3) Pro Series Full Width Equipment 17.6K
17,600 lbs
Model #:
CBIT10220-BP-176
GVWR:
17,600 lbs
GAWR:
8,000 lbs/axle
Curb Weight:
4,560 lbs
8.5 x 20
(17+3) Pro Series Full Width Equipment 22K
22,000 lbs
Model #:
CBIT10220-BP-220
GVWR:
22,000 lbs
GAWR:
10,000 lbs/axle
Curb Weight:
4,760 lbs
8.5 x 22
(19+3) Pro Series Full Width Equipment 15.4K
15,400 lbs
Model #:
CBIT10222-BP-154
GVWR:
15,400 lbs
GAWR:
7,000 lbs/axle
Curb Weight:
4,450 lbs
8.5 x 22
(19+3) Pro Series Full Width Equipment 17.6K
17,600 lbs
Model #:
CBIT10222-BP-176
GVWR:
17,600 lbs
GAWR:
8,000 lbs/axle
Curb Weight:
4,800 lbs
8.5 x 22
(19+3) Pro Series Full Width Equipment 22K
22,000 lbs
Model #:
CBIT10222-BP-220
GVWR:
22,000 lbs
GAWR:
10,000 lbs/axle
Curb Weight:
5,108 lbs
Features and Specifications subject to change without notice. Please contact your local dealer for confirmation.
