Equipment Trailer
The Equipment Trailer is designed for versatility and durability across a wide range of jobs and applications. Built with a rugged C-Channel frame and cross-members, this trailer is engineered to withstand the toughest work environments, providing the strength and reliability you need to haul your equipment with confidence. Available in multiple lengths and Gross Vehicle Weight Rating of 10K, 14K, and 16K, you can be sure to find a configuration that meets your demands.
Bed Width:
7'
Bed Length:
16' - 24'
GVWR:
9,900 - 16,000 lbs
Load Capacity:
6,950 - 12,660 lbs
Key Benefits
Full Wrapped C-Channel Tongue
Provides exceptional structural integrity with increased strength and durability. Also enhances stability of the tongue when under load.
Heavy Duty Drop Leg Setback Jack
Equipped with a jack that allows for quick and easy unhitching, as well as being located in a position to clear your tailgate.
2′ Beavertail and HD 4″ Channel Stand-Up Ramps
Provide an optimal loading angle for safe loading, while the spring-assist features reduces the strain and effort required.
Spring-Assist Ramps with Adjustable Support Legs
Ensures stable and secure loading in any conditions.
Pressure Treated 2″ x 6″ Decking
More resistant to rot and decay and provides strength and stability to handle whatever you’re hauling.
(4) D-Rings
Securely tie down your cargo with these heavy-duty anchor points, providing extra stability and safety during transport.
Stake Pockets and Rub Rail
Enables you to customize the trailer’s configuration to meet your specific hauling needs, and provide support and a more finished look to the trailer.
Why Choose a Sure-Trac Equipment Trailer?
One of the key features of the Equipment Trailer is its 2-foot beavertail, which provides an easier and smoother transition for loading and unloading your equipment. Paired with the spring-assist channel ramps, this trailer makes handling even heavy machinery a more manageable task. The spring-assist ramps reduce the effort needed to raise and lower them, saving you time and energy during the workday.
In addition, the ramps are equipped with adjustable support legs, allowing you to load equipment on uneven or soft ground without worrying about stability. This ensures safer loading conditions in various environments, whether you’re at the job site, in the field, or on a slope.
Designed for versatility, the Equipment Trailer can handle a wide range of applications, from transporting compact construction equipment to hauling heavy-duty machinery for agricultural or landscaping projects. Its robust construction and thoughtful design features make it ideal for professionals who need a dependable trailer that can adapt to different tasks.
Whether you’re moving tractors, skid steers, or other essential equipment, the Equipment Trailer is built to provide years of reliable service. It combines the traditional functionality of an equipment trailer with modern enhancements for ease of use, safety, and durability. Whatever the job, the Equipment Trailer is ready to help you get it done efficiently and effectively.
Red
Orange
Yellow
Green
Blue
Gray
Models & Sizes
7 x 16
(14+2) Equipment Trailer, 10K
9,900 lbs
Model #:
C8216ET-B-100
GVWR:
9,900 lbs
GAWR:
5,000 lbs/axle
Curb Weight:
2,550 lbs
7 x 16
(14+2) Equipment Trailer, 14K
14,000 lbs
Model #:
C8216ET-B-140
GVWR:
14,000 lbs
GAWR:
7,000 lbs/axle
Curb Weight:
2,800 lbs
7 x 16
(14+2) Equipment Trailer, 16K
16,000 lbs
Model #:
C8216ET-B-160
GVWR:
16,000 lbs
GAWR:
8,000 lbs/axle
Curb Weight:
3,340 lbs
7 x 18
(16+2) Equipment Trailer, 10K
9,900 lbs
Model #:
C8218ET-B-100
GVWR:
9,900 lbs
GAWR:
5,000 lbs/axle
Curb Weight:
2,750 lbs
7 x 18
(16+2) Equipment Trailer, 14K
14,000 lbs
Model #:
C8218ET-B-140
GVWR:
14,000 lbs
GAWR:
7,000 lbs/axle
Curb Weight:
2,870 lbs
7 x 18
(16+2) Equipment Trailer, 16K
16,000 lbs
Model #:
C8218ET-B-160
GVWR:
16,000 lbs
GAWR:
8,000 lbs/axle
Curb Weight:
3,540 lbs
7 x 20
(18+2) Equipment Trailer, 10K
9,900 lbs
Model #:
C8220ET-B-100
GVWR:
9,900 lbs
GAWR:
5,000 lbs/axle
Curb Weight:
2,950 lbs
7 x 20
(18+2) Equipment Trailer, 14K
14,000 lbs
Model #:
C8220ET-B-140
GVWR:
14,000 lbs
GAWR:
7,000 lbs/axle
Curb Weight:
3,195 lbs
7 x 20
(18+2) Equipment Trailer, 16K
16,000 lbs
Model #:
C8220ET-B-160
GVWR:
16,000 lbs
GAWR:
8,000 lbs/axle
Curb Weight:
3,720 lbs
7 x 22
(20+2) Equipment Trailer, 14K
14,000 lbs
Model #:
C8222ET-B-140
GVWR:
14,000 lbs
GAWR:
7,000 lbs/axle
Curb Weight:
3,500 lbs
7 x 22
(20+2) Equipment Trailer, 16K
16,000 lbs
Model #:
C8222ET-B-160
GVWR:
16,000 lbs
GAWR:
8,000 lbs/axle
Curb Weight:
4,380 lbs
7 x 24
(22+2) Equipment Trailer, 14K
14,000 lbs
Model #:
C8224ET-B-140
GVWR:
14,000 lbs
GAWR:
7,000 lbs/axle
Curb Weight:
3,680 lbs
7 x 24
(22+2) Equipment Trailer, 16K
16,000 lbs
Model #:
C8224ET-B-160
GVWR:
16,000 lbs
GAWR:
8,000 lbs/axle
Curb Weight:
4,420 lbs
Features and Specifications subject to change without notice. Please contact your local dealer for confirmation.
